Digital Adhesion Meter
Product introduction
Digital adhesion meter fast, effective and accurate measurement of viscosity, provides an ideal solution, it is easy to use, wide application, can be used for detection of various liquids. Measurement of torque, rotational speed can be displayed, rotor model, and the results calculated viscosity.
9. 8 languages selectable
10. When the reading in the full scale and below 15% will alarm
Technical parameters of Digital Adhesion Meter
Measurement range | 100 mPa•s~2×105 mPa•s (If you select the No.30 spindle, the measurement range can be extended to 4×105 mPa•s) |
Rotor Specifications | No.21, 27, 28 and 29 total 4 pieces of spindles (the No.30 spindle is optional) |
Rotor speed | (5,10,20,50)r/min |
Measurement error | ±1% (F•S); (If you select the No.30 spindle, it will be ±3% (F•S) |
Temperature control range | 45 ℃~200 ℃ |
Temperature control accuracy | ±0.1 ℃ |
Sample cylinder | 20ml |
Print output | Needle printer |
Communication with the PC | RS232 interface |
Power supply | AC 220V±10%, 50 Hz |
Ambient temperature | 5 ℃~35 ℃ (when the controlling temperature is close to ambient temperature, please run the air conditioner to let the ambient temperature be 5 ℃ lower than the controlling temperature) |
Relative humidity | ≤80% |
Technical features.
*Inch touch screen, easy to operate, rich display information
*Anti-static housing, PC lift bar
*RTD temperature probe option
*ARM chip processor, faster data processing speed
*Durable new small axis design
*Powerful human-machine interface
*Automatic conversion of kinetic and kinematic viscosities
*Interchangeable viscosity units
*Complete with operating aid and viscosity correction
*Continuous change of viscosity value display
*Alarm for exceeding the measurement range
*Computerised full range linearity correction
*AC power adapter 100V-240V, good immunity to interference
Measuring range mPa.s 1 - 2 million
Rotor speed (rpm) 0.3,0.6,1.5,3,6,12,30,60
Number of rotors 4 types of rotors 1,2,3,4
±1.0% (full scale)
Repeatability ±0.2%
What is the purpose of adhesion test?
The basic goal of adhesion testing is to produce a coating failure. The coating under test may experience an interface failure between the substrate and coating or between the individual coating layers in a multi-layer application. Coatings may also experience a cohesive failure within a particular layer.
Is standard for adhesion test?
ASTM D3359 is a standard test methods for measuring adhesion by tape test. This test assesses the adhesion of film coatings to metallic substrates by applying and removing pressure-sensitive tape over cuts made in the film. This test method is also known as the Cross Hatch test.
