Standard：GB/510、ASTM D2386、GB/T3535、ASTM D97

Features

1. Liquid crystal display, touch control, easy to use.

2. It can be heated (sample) to 50℃ or refrigerated to -70℃.

3. Automatic detection, automatic printing results, and good repeatability.

4. Automatic tilting during detection, in line with the standard.

5. High-performance compressor refrigeration, long service life.

6. The test method is optional, which can be quickly detected or normal detected.

7. With fault diagnosis and other functions, it can prompt operation.

8. Refrigeration speed and testing standards can be prepared according to customer requirements.

Specification

• Measuring range: room temperature～-70℃

• Measurement accuracy: ±1℃

• Resolution: 0.1℃

• Display mode: LCD display

• Screen: 7-inch LCD screen

• Sample volume: pour point 6ml, pour point 40ml

• Number of samples: 1

• Printer: thermal type, 36 characters, Chinese character output

• Ambient temperature: 5℃～45℃

• Relative humidity: ≤85%

• Working power: AC220V±10% 50Hz

• Power consumption: 900W

• Dimensions: 400mm×800mm×500mm (W×H×D)

• Weight: 50kg
