Description

Inductively coupled plasma emission spectrometer, also known as ICP spectrometer (Inductive Coupled Plasma), uses inductively coupled high-frequency plasma as the excitation light source and uses the atomic or ion emission characteristic spectrum of each element to determine the composition of the material and to carry out the qualitative analysis of the element. with quantitative analysis instruments. Also known as ICP Atomic Emission Spectrometer.

Features

1. Full Chinese operation interface, with drawing function, easy to use.

2. Computer-controlled automatic peak finding, automatic scanning and automatic attenuation.

3. Interference correction between single and complex elements.

4. Automatic background correction and background subtraction.

5. The spectral line library stores more than 24,000 analytical spectral lines, which can be added by yourself.

6. Automatic diagnosis and debugging after startup.

7. The measurement method of quadratic regression and Gaussian curve calculation content.



Specification

• Fast analysis speed: the fastest analysis of more than 20 elements in one minute

• High precision: relative standard deviation RSD≤1.5%

• Good stability: relative standard deviation RSD≤2.0%

• Low detection limit: μg∕L

• Multiple analysis elements: Quantitative analysis of more than 70 elements

• Ease of use: The new Windows operating environment is fully functional

• Fully automatic ignition: reduce the difficulty of use, convenient and fast

• Multile safety protections: low-volume cooling water reminder protection, argon low-value protection, arc extinguishing protection, triple protection is safer to use

• Power supply (power grid fluctuation ≥10%, AC voltage stabilizer is required):

Spectrometer: AC 220V 30A

Computer: AC 220V 2 A

Water tank: AC 220V 8 All
