- Site：Home > Leather and Footwear Testing Instruments > SL-L13 Insole Backpart Stiffness Tester
- Product Images
- detailed description
Insole Backpart Stiffness Tester
Application
Leather stiffness tester machine is used to measure the stiffness in the longitudinal direction ofsteel shanks used for the reinforcement of the waist region of shoes, the shank is clamped at its heel end and bent as a cantilever beam by masses added to its forward ,then calculate the flexural rigidity of the shank.
Technical parameters
Rotation angle 30 ° Length of measuring clip 60±0.002mm Front clamp D 12mm Dimension 200g*4sets Dial Gauge 0~10mm(min graduation0.01mm ) Dead Weight 200+/-1g×4 Dimension (W×D×H)37x17x35cm Weight 12kg
Testing Standards
BS 5131/4.18, QB/T 1812, QB/T 1813
What is the purpose of footwear testing?
Physical test on footwear, textiles or clothing, physical test in leather goods and Luggages. To evaluate the performance of the product, its comfort, its safety and its quality (resistance to slipping, abrasion, permeability, flexion, heel impact, etc.).
