SL-E12 Thermal Shock Test Chamber
Product introduction
High formula memory capacity may be set to 120 patterns. The maximum cycle setting is 9999cycles. The maximum setting of each section is 999 Hrs 59 Mins.
Provide with RS-232C communication interface device, capable of controlling / editing/ recording in the linkage with the computer and two set dynamic connection point and convenient application.
Both 2 zone and 3 zone shocks can be chosen.
All equipment is fully automatic, and all process are precisely controlled with P.L.C.’S.
Of any part of the malfunctions, the machine will automatically shuts down and a warning light switches on.
Machine can be shut down automatically in case of electrical power instabilities.
Technical parameters
Internal Dimension: (W×H×D)50×50×50 cm
Structure: Two chambers design(the hot chamber or the cold chamber)
Damper device: Forced air drive damper
Interior material: SUS# Stainless steel plate
Exterior material: SUS# Stainless steel plate
Basket material: SUS# Stainless steel plate
Refrigeration: Cascade refrigeration system
Cooling method: Water
Ambient temperature: 0°~30°
Preheating temperature: above freezing 60.00°C~above freezing200.00°C
Pre-cooling temperature: subzero 10.00°~ subzero 70.00°C
H.T. Shocking: above freezing 60.00°C~above freezing 150.00°C
L.T. Shocking: subzero 10.00°C~subzero 65.00°C
Temperature uniformity: ±2.00°C
Simulated load ic 5.0kg
HT IN-Zone subzero 65.00°C~above freezing 150.00°C/5min
LT IN-Zone above freezing 150.00°C subzero 65.00°C
Preheating time: 45MIN
Pre-cooling time: 75MIN
What is thermal shock chamber?
Thermal shock chambers are the means through which alternating extreme hot and cold air is applied to products to test their durability and identify breaking points. The method reduces the potential for failures.
How does an environmental chamber work?
An Environmental Chamber is an enclosed space where environmental conditions such as temperature and humidity can be controlled. Some chambers can also simulate corrosion by introducing salt spray into the chamber. The dimensions of these chambers may greatly vary according to the type of product that has to be tested.
